Product Comparison

Sensor & Image

Capture
Flat(Single) fingers
Capture
Flat(Single) fingers
Capture
Flat(Single) fingers
Sensor Type
Optical
Sensor Type
Optical
Sensor Type
Optical
Resolution
500 ppi
Resolution
500 ppi
Resolution
500 ppi
Grayscale
8-bit, 256 levels
Grayscale
8-bit, 256 levels
Grayscale
8-bit, 256 levels
Image Size (WxL)
400 x 500 pixels
Image Size (WxL)
300 x 400 pixels
Image Size (WxL)
300 x 400 pixels
Template Format
Xperix, ISO19794-2, ANSI 378
Template Format
Xperix, ISO19794-2, ANSI 378
Template Format
Xperix, ISO19794-2, ANSI 378
Supported Image Formats
RAW, BMP, ISO 19794-4, WSQ(FBI certified)
Supported Image Formats
RAW, BMP, ISO 19794-4, WSQ(FBI certified)
Supported Image Formats
RAW, BMP, ISO 19794-4, WSQ(FBI certified)
Encryption
Device: AES-256, RSA 1024bit, ECC 521bit
SDK: AES-256
Encryption
Device: AES-256, RSA 1024bit, ECC 521bit
SDK: AES-256
Encryption
SDK: AES-256
FBI / Image Certifications
Mobile ID FAP 30 (PIV-071006), PIV Single Finger (PIV-071006), FIPS
FBI / Image Certifications
Mobile ID FAP 20 (PIV-071006), PIV Single Finger (PIV-071006), FIPS
FBI / Image Certifications
Mobile ID FAP 20 (PIV-071006), PIV Single Finger (PIV-071006)

System

OS Support
Windows 7 or higher 32/64bit
Linux Ubuntu, Debian, Fedora, OpenSUSE, CentOS 32/64bit
Android 5.0 or higher (USB Host)
OS/Platform Independent, Stand-alone Operation
OS Support
Windows 7 or higher 32/64bit
Linux Ubuntu, Debian, Fedora, OpenSUSE, CentOS 32/64bit
Android 5.0 or higher (USB Host)
OS/Platform Independent, Stand-alone Operation
OS Support
Windows 7 or higher 32/64bit
Linux Ubuntu, Debian, Fedora, OpenSUSE, CentOS 32/64bit
Android 5.0 or higher (USB Host)

Weight & Dimensions

Durability

Power & Connectors

General

Live Finger Detection(LFD)
Supported (by AI-based)
Live Finger Detection(LFD)
Supported (by AI-based, ISO/IEC 30107-3 PAD Level 1 & 2 Compliant)
Live Finger Detection(LFD)
Supported (by AI-based, ISO/IEC 30107-3 PAD Level 1 & 2 Compliant)
Plug & Play
Supported (by HID Protocol)
Plug & Play
Supported (by HID Protocol)
Plug & Play
Not Supported
Stand-alone Mode
Supported
Stand-alone Mode
Supported
Stand-alone Mode
Not Supported
Multi Dynamic Range(MDR)
Supported
Multi Dynamic Range(MDR)
Supported
Multi Dynamic Range(MDR)
Supported
Sound
Not Supported
Sound
Not Supported
Sound
Not Supported
LED Indicator
Not Supported
LED Indicator
Not Supported
LED Indicator
Not Supported
Kensinton lock
Not Supported
Kensinton lock
Not Supported
Kensinton lock
Not Supported

Certification

Certification
FBI, CE, FCC, KC, RoHS, USB-IF, CB, IEC 62471, WEEE, REACH, BIS, WHQL
Certification
FBI, CE, FCC, KC, RoHS, CB, IEC 62471, WEEE, REACH, WHQL, PAD Level 1 & 2 by BixeLab
Certification
FBI, CE, FCC, KC, RoHS, CB, IEC 62471, WEEE, REACH, BIS, USB-IF, WHQL, PAD Level 1 & 2 by BixeLab

Card

Security
